Send Inquiry33KV Indoor SF6 Switchgear Panel
Price 800000 INR/ Piece
MOQ : 1 Piece
33KV Indoor SF6 Switchgear Panel Specification
- Rated Voltage
- 33KV
- Capacity
- 800A
- Standard
- IEC 62271-200
- Operating Temperature
- -10C to +45C
- High Voltage
- 33KV
- Dimension (L*W*H)
- 1200 mm x 2800 mm x 2200 mm
- Load Loss
- <1% of Rated Power
- Coil Material
- Copper
- Cooling Type
- Air Cooled
- Low Voltage
- Control Circuit: 110V DC
- Product Type
- Switchgear Panel
- Material
- Mild Steel
- Output
- 33KV
- Frequency (MHz)
- 50 Hertz (HZ)
- Efficiency
- 99.5%
- Phase
- Three Phase
- Usage
- Industrial
- Power Scope
- 33KV
- Weight
- Approx. 750 kg
- Interlocking System
- Mechanical & Electrical
- Insulating Medium
- SF6 Gas
- Protection Relays
- Microprocessor Type
- Panel Configuration
- Single/Double Busbar
- Control Voltage
- 110V/220V DC
- Degree of Protection
- IP4X
- Panel Color
- RAL7032
- Short Circuit Withstand
- 25kA for 3 Sec
- Installation Type
- Indoor
- Feeder Type
- Incoming/Outgoing
33KV Indoor SF6 Switchgear Panel Trade Information
- Minimum Order Quantity
- 1 Piece
- Supply Ability
- 100 Pieces Per Month
- Delivery Time
- 7 Days
- Main Export Market(s)
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- Main Domestic Market
- All India
About 33KV Indoor SF6 Switchgear Panel
Medium voltage based 33KV,Indoor SF6 Switchgear Panel is accessible in floor mounted design. Developed from mild steel, this switchgear panel has complete protection against vertical water spray. This switchgear panel is suitable for effective protection of HT capacitor, power transformer and generator. Provided 33KV,Indoor SF6 Switchgear Panel has modular construction and compact structure. All its parameters are flexible to suit specific application needs of different industries. This switchgear panel has advanced mechanism to prevent hazardous condition associated with mishandling of its breaker.
Advanced Protection and Safety
Equipped with microprocessor-based relays and a dual interlocking system, the 33KV Indoor SF6 Switchgear Panel ensures comprehensive protection against electrical faults. The robust design underpins the safety of operations, helping businesses prevent equipment damage and downtime.
Versatile Configuration and High Efficiency
Choose between single or double busbar setups to match your exact operational requirements. The panel maintains a remarkable efficiency level of 99.5%, keeping operational costs low while supporting up to 800A capacity. Its engineered for adaptability within diverse industrial environments.
Adapted for Harsh Industrial Environments
With an IP4X protection rating, an air-cooled system, and reliable performance across a wide operating temperature range (-10C to +45C), this panel is designed for durability in demanding conditions. The use of high-quality materials, including mild steel and copper coils, further ensures longevity.
FAQs of 33KV Indoor SF6 Switchgear Panel:
Q: How does the SF6 insulating medium contribute to the performance of the switchgear panel?
A: The SF6 gas offers excellent electrical insulation and arc-quenching properties, allowing the switchgear panel to operate safely at high voltages and minimize the risk of short circuits or electrical failures.Q: What is the installation process for this 33KV indoor SF6 switchgear panel?
A: The panel is intended for indoor installation, typically by qualified technicians. It involves mounting the unit, connecting incoming and outgoing feeders, integrating the control circuit at 110V DC, and verifying all mechanical and electrical interlocks.Q: Where can this switchgear panel be used most effectively?
A: This panel is ideal for industrial environments where high voltage control, reliability, and safety are paramount, such as manufacturing facilities, substations, and utility stations.Q: What benefits do the microprocessor-based protection relays provide?
A: Microprocessor-based relays deliver precise and rapid fault detection, enhance automation, and offer advanced diagnostic capabilities for improved system protection and streamlined maintenance.Q: When should maintenance be performed on the SF6 switchgear panel?
A: Routine visual inspections should be conducted periodically, while comprehensive testing and maintenance are recommended annually or as specified by operational guidelines, to ensure long-term efficiency and safety.Q: How does the interlocking system improve operational safety?
A: The combination of mechanical and electrical interlocks ensures coordinated and secure switching operations, preventing unsafe actions and reducing the risk of accidental faults or operator errors.
